SM500
RITSCHER
The SM500 DC Linear Actuator is designed for electric recliners, adjustable beds, and smart furniture systems that require stable linear movement and reliable load performance.
Powered by 12V or 24V DC input, this actuator provides up to 6000N push force and 4000N pull force, making it suitable for heavy-duty lifting, reclining, and adjustment mechanisms.
With optional Hall sensor feedback, the SM500 actuator can provide accurate position control for applications requiring synchronized movement and precise adjustment.
It is an ideal solution for furniture manufacturers looking for a compact, quiet, and durable electric linear motion system.
The SM500 linear actuator delivers powerful mechanical movement with:
Maximum push force up to 6000N
Maximum pull force up to 4000N
Stable operation under continuous furniture adjustment requirements
It helps electric sofas, recliners, and adjustable beds achieve smooth lifting and reclining functions.
The actuator supports both 12V DC and 24V DC power supplies, allowing manufacturers to select the suitable voltage according to their control system design.
Benefits include:
Flexible system integration
Easy connection with control boxes
Suitable for different furniture platforms
The SM500 can be equipped with an optional Hall sensor system for accurate position detection.
Hall sensor feedback helps:
Monitor actuator position
Achieve synchronized movement
Improve adjustment accuracy
Support intelligent furniture control systems
This option is especially suitable for premium electric sofas and adjustable beds.
Item | Specification |
|---|---|
Model | SM500 |
Product Type | DC Linear Actuator |
Input Voltage | 12V DC / 24V DC |
Maximum Push Force | 6000N |
Maximum Pull Force | 4000N |
Stroke Length | Customized |
Feedback Option | Hall Sensor Available |
Motor Type | DC Motor |
Application | Electric Sofa, Recliner, Adjustable Bed |
Installation | Customized Mounting Options |
Technical specifications can be customized according to different application requirements.
Different furniture applications require different combinations of force and speed.
The SM500 actuator can be configured according to:
Requirement | Recommended Configuration |
|---|---|
Heavy-duty recliner | Higher load version |
Adjustable bed lifting | High stability configuration |
Electric sofa mechanism | Balanced speed and force |
Smart furniture system | Hall sensor feedback version |
Our engineering team can help select the suitable actuator configuration based on:
Required load
Stroke length
Operating speed
Installation space
Control system
The SM500 provides smooth and reliable movement for electric recliner systems.
Typical applications include:
Home theater seats
Luxury recliners
Commercial seating
Massage chairs
The compact design allows easy integration into different furniture structures.
For adjustable beds, stable lifting performance is critical.
The SM500 supports:
Backrest adjustment
Leg elevation
Mattress platform movement
Multi-position adjustment systems
Its high load capacity helps maintain smooth operation during repeated use.
The actuator can be integrated into intelligent furniture systems with:
Control boxes
Remote controllers
Position feedback systems
Synchronized motion control
The actuator uses a strong transmission structure to provide stable linear movement.
Advantages include:
High load capability
Long service life
Smooth operation
Low maintenance requirements
The SM500 is developed for OEM furniture applications.
We support:
Customized stroke length
Voltage selection
Feedback options
Mechanical structure adjustment
Bulk production requirements
The actuator can work together with:
Electric sofa control systems
Adjustable bed control boxes
Smart furniture controllers
It helps manufacturers build complete electric adjustment solutions.
Before selecting an actuator, consider the following factors:
Confirm the required pushing and pulling force.
For heavy furniture applications, choose a higher force actuator to ensure stable operation.
Stroke determines the movement distance.
Common factors include:
Reclining angle
Bed adjustment range
Installation space
Choose according to your control system:
12V DC systems
24V DC systems
Choose Hall sensor feedback when your application requires:
Accurate positioning
Multiple actuator synchronization
Smart control functions
A DC linear actuator converts the rotary motion of a motor into linear movement.
It is commonly used for lifting, pushing, pulling, and adjustment applications.
The SM500 provides:
Up to 6000N push force
Up to 4000N pull force
It is suitable for heavy-duty electric furniture applications.
Yes.
A Hall sensor option is available for applications requiring position feedback and synchronized control.
The SM500 is widely used for:
Electric recliners
Adjustable beds
Electric sofas
Smart furniture systems
